Wander Luminaire Family

Wander is a broad family of luminaires offering multiple mounting configurations - pedestal, semi-recessed and surface mount - that provide visual continuity for pathways, step, and surface lighting applications. With a robust build and exceptional performance, Wander seamlessly blends into its surroundings and minimizes environmental impact with its low-profile design.

Wander From Now On

Uniquely designed to provide a wide lateral distribution that meets IES egress requirements from up to 25FT on-center fixture spacings. Its design, combined with its proprietary precision high-clarity acrylic optic, prevents scattered light from disrupting the night skies and stops light from spilling unnecessarily.

250107_HYDREL_WATERFRONT_OPT_01 copy
241212HYDRELWANDERCANOPY 3 copy

Wander offers three tailored distributions for a wide range of applications with no striations or color separation. Options range from very wide lateral spread to long forward illumination to achieve tailored and unprecedented fixture spacing and superior uniformity.

The result is the ability to light environments with fewer luminaires. With up to 50% more coverage, Wander is genuinely a high-performing luminaire.

241212HYDRELWANDERCANOPY 3 copy
241129HYDRELWANDERUNIVERSITY 4 copywide

Fixture Spacing Calculation*

Footprint From On-Center Fixture Spacing

Wander OH DL Distribution Width Length
1 18" 300 LM
MW
SW
6ft
9.5ft
12.5ft
7.5ft
6.5ft
5ft
1 34" 300 LM
MW
SW
8ft
12ft
15ft
10ft
8.5ft
7.5ft
1 18" 500 LM
MW
SW
8ft
11ft
14.5ft
8ft
7ft
5.5ft
1 34" 500 LM
MW
SW
8.5ft
9.5ft
10.5ft
11.5ft
16ft
18.5ft
3 18" 1000 LM
MW
SW
7.5ft
13ft
16.5ft
10ft
8.5ft
6.5ft
3 34" 1000 LM
MW
SW
12ft
16.5ft
22.5ft
14ft
13ft
10ft
3 18" 1500 LM
MW
SW
8ft
14ft
18.5ft
11ft
9ft
7ft
3 34" 1500 LM
MW
SW
13ft
20ft
25ft
15ft
13ft
11ft
Note:
OH: Optic Height
DL: Delivered Lumens

* Calculation assumes continuous fixture spacing to achieve 1fc egress minimum.
General Guidelines and Recommendations:
1500-delivered lumen package: Best use with a 34" optic height.
300-delivered lumen package: Best with 18" optic height or low illuminance level applications.

For more details on fixture spacing, please download the brochure.

Features

Features
  • 3 tailored distributions
  • 2 fixture heights with pedestal
  • 2 sizes, one optic or 3 optics selection
  • Single or dual head configuration
  • Pedestal, semi-recessed and surface mounts
  • Flow-Thru Technology
  • IK10
  • 3G
  • IP67
  • BUG U0 compliant
Benefits
  • Broad family of pathway, step and surface luminaires provide visual continuity
  • Offers a maximum wide lateral spread of up to 25ft on-center fixture spacing
  • Up to 50% more coverage based on options and performance package selected
  • No striations or color separation
  • Offers opportunity for wider fixture spacing and fewer luminaires
  • Meets 1fc egress lighting requirements
  • Static white, Amber Limited Wavelength 590nm, Red, Blue and Green
  • Simple aesthetic that blends into its surroundings
  • Proprietary precision high clarity acrylic optic
  • Custom optic design
Controls
  • 0-10V
  • Reverse Phase

Lumens
  • 300 to 1500 delivered lumens

Distribution

The Wander Effect

Discover "The Wander Effect"! Wander sets a new standard for exterior pathway illumination. It offers true performance advantages with a robust build, making it a luminaire that fits tough urban lighting requirements.
